Description
| Model | HBWS15S |
|---|---|
| Split Force | 15t |
| Log Capacity | 525mm |
| Control valve | Auto Return with Adjustable Detent |
| Pump Size | 10 GPM |
| Cylinder inner Diameter | 3inch |
| Hydraulic Rod Diameter | 44.5mm |
| Hydraulic Cylinder Stroke | 502mm |
| Cylinder Cycle Time | 10S |
| Hydraulic Capacity （L） | 9L |
| Fuel Capacity (L) | 3.6L |
| Whether the hydraulic oil is pre filled | Not Included |
| Size of cleaver | 165mm |
| Tire | 10inch |
| Engine | 7HP |
| Overall dimensions | 1422×580×1189 |
| Net weight | 140kgs |
| Gross weight | 160kgs |
| Package Size | 830×455×1150mm |
